LEMKEN Primus 10 - Pressure Filter

Cleaning
140
 When mounting, ensure the seal (4) is
correctly inserted and not crushed.
7.5.3 Pressure filter
Preconditions:
 Nozzles are switched off.
 The diverting valve is switched to exter-
nal cleaning/pumping.
 Connection for external cleaning/ pum-
ping is sealed with a sealing cap.
 Remaining spray agent is drained from
the pressure filter (3) and system
through the rinsing valve.
 Flushing valve (F) closed to the stop by
turning it to the right.
4
F
