LEMKEN Primus 10 - Hand-Wash Tank; Filter; Pump(S)

Layout and description
48
4.8 Hand-wash tank
The hand-washing tank (1) is designed for
receiving clean water. For example to faci-
litate handwashing.
4.9 Filter
Functional and clean filters are a prerequi-
site for trouble-free operation.
The device comes complete with the follo-
wing filters:
 One or two suction filter/s (1), which filter
the suction side volumetric flow to the
pump.
 Pressure filter (2) which filters the pres-
sure-side volumetric flow to the nozzles.
4.10 Pump(s)
The unit is equipped with one or two
pumps (1) depending on the configuration.
The pumps are designed to convey
spraying fluids.
The pumps are driven mechanically via a
cardan shaft.
1
2
1
1
