LEMKEN Primus 10 - Connections; Pressure Limiting Valve

Layout and description
54
4.11.6 Connections
The following connections are available:
 Filling opening (1) of the handwashing
container
 Filling opening (2) of the clean water -
container
 Intake connection (3)
 External cleaning/pumping (4)
 Filling port (not shown)
4.11.7 Pressure limiting valve
The pressure limiting valve (1) is used to
adjust the maximum system pressure of
the implement.
The pressure limiting valve is set at the
factory and must not be adjusted.
3
2
1
4
1
