LEMKEN Primus 10 - Spraying Fluid System

Technical data
188
Type
P 260
P 200/P200
Rated speed [rpm]
540
Speed range [rpm]
450 - 700
Volumetric flow at 5 bar and rated
speed [l/min]
520
400
Power consumption[KW] at rated speed
and 5 bar
10.2
7.1
Oil type
SAE 15W40
Approximate oil quantity [l]
1.7
2 x 1.3
Approximate weight [kg]
56.0
50.0
Membrane material
Rubber
Number of pressure accumulators
2
10.12 Spraying fluid system
Spraying pressure range of implement with water [bar]:
1.0 – 8.0
Permissible system pressure [bar]
10
Application quantity depending on pump, nozzles and speed of
travel [l/ha]:
200 – 600
Connections
Hand washing container:
 Drain: Hose connector Ø 13 mm
 Filling GeKa connector
Fresh water tank
(Fresh water tank filling and
emptying connections):
GeKa connector
External cleaning/pumping:
1.5" Kamlock connector
Suction connector
2" Kamlock connector
Filling connector
2" Kamlock connector
