LEMKEN Primus 10 - Cable; Sprayer Boom

Maintenance and servicing
156
9.4.9 Cable
Lubrication interval:
 Every 50 operating hours
 After cleaning, lubricate the ropes with
lubricant for wire ropes.
9.4.10 Sprayer boom
Lubrication interval:
 Every 8 operating hours
The following lubrication points are located
on the right and left side of the boom.
Images with the lubrication points are only
shown from one side of the boom. The
number of lubrication points shown refers
to the total number of points on both the
right and left side of the boom.
Vibration damper
 Lubricate 2 grease nipples (1) on the
vibration damper.
1
1
