LEMKEN Primus 10 - Technical Remaining Quantities; Matrices; Pump P 260

Appendix
209
11.7 Technical remaining quantities
Device
Rated tank volumes [l]
Boom width, maximal [m]
Remaining quantity [l]
Level
Slope
Contour line
Up, 8.5°
Down, 8.5°
Dilutable
Non-dilutable
Total
Left, 8.5°
Right, 8.5°
2500
3500
4500
11.8 Matrices
11.8.1 Pump P 260
Configuration
*
Main tank
Sprayer boom
B 21/
B 27
B 30
7
TB
9
TB
7 TB
9 TB
9 TB
2400 l
3300 l
FS 21/15 m | 7x3 m
FS 21/15 m | 1/2/5x3/2/1 m
FS 15/00 m | 1/2/3x3/2/1 m
FS 18/00 m | 1.5/5x3/1.5 m
FS 18/00 m | 1/2/1.5/3x3/1.5/2/1 m
FS 21/18 m | 1/2/5x3/2/1 m
FS 24/18 m | 2/3/2.5/3x3/2.5/3/2 m
FS 24/18 | 1/2/3.5/4/3/4/3.5/2/1 m
FS 27/18 m | 1.5/3/3.5/4/3/4/3.5/3/1.5 m
FS 24/20 m | 2/2x2.5/3.5/3/3.5/2x2.5/2 m
FS 27/20 m | 1.5/2/4/4.5/3/4.5/4/2/1.5 m
FS 28/20 m | 2x2/4/4.5/3/4.5/4/2x2 m
FS 30/20 m | 2x2.5/4/4.5/3/4.5/4/2x2.5 m
P10-2500-001
x
x
