LEMKEN Primus 10 - Intake Connection

Operation
94
6.4.3 Intake connection
Application: Pump water or ready-mixed
spraying fluid with the intake connection
into the main tank.
The maximum suction depth with a filling
hose is 2.5 m.
*Position designations correspond to the position de-
signations of the fluid lines, see "Liquid flow, page 39".
Approach*
 Switch on operation terminal.
 Switch on the PTO shaft.
The pump is switched on and driven via
the PTO shaft.
 Operate pump at a maximum of
550 rpm.
 Remove the blind cap of the suction
port (1).
 Attach the filling hose to the suction
port (1).
 Hold filling hose in an external tank
Or
attach the filling hose to the water
connection provided..
 Set the selection valve of the spray
pump (A) to external.
 Device with 4500 l:Set the selection val-
ve of the stirring pump (B) to external.
1
