11.6 Layout plan for electrohydraulic operation;
Positioning the hydraulic valves
Sprayer boom is controlled with electrohydraulic operation.
Raising and lowering the boom
Raise
Lower
Completely folding the boom or arm 1
Extend
Fold in
Folding arm 2
Extend
Fold in
Hydraulic slope compensation
Lower left
Lower right
