LEMKEN Primus 10 - Sprayer Boom; B21

Technical data
191
 If the load capacity of the wheels is lower than the permissible axle load, the
permissible axle load shall be reduced to the permissible load capacity of the
wheels.
 Please note that when spraying heavier agents (e.g. AHL) the filling quantity of
the containers must be reduced.
10.17 Sprayer boom
Operating pressure [approx. bar]
10
Nozzle distance to the ground, depending on tyres [approx. m]
2.0 or 2.5
Boom swinging range [approx. °]
17
10.17.1 B21
(1) From left to right
// = Reduction
Sprayer boom
Overall working width [m] - folded out
Transport width [approx. m]
Weight [approx. kg]
Number of nozzles
Number of part-width sections
Part-width sectioning [m](1)
// Overall working width [ap- prox. m]
// Spraying width
// Part-width sectioning [m](1)
// Weight [approx. kg]
FS 21/15 - 7 B21
21
2.70
755
42
7
7x3
15
15
3//5x3//3
767
FS 21/15 - 9 B21
21
2.70
9
1/2/5x3/2/1
1//5x3//1
