LEMKEN Primus 10 - Skids and Pivoted Guide; Cable Pulley

Maintenance and servicing
155
9.4.7 Skids and pivoted guide
Lubrication interval:
 Every 8 operating hours
 Lubricate the grease nipple on the self-
aligning bearing (1).
 Lubricate both the right and left grease
nipples on the pivoted guide (2).
 Lubricate the four left (3) and four right
grease nipples (4) on the skids.
9.4.8 Cable pulley
Lubrication interval:
 Every 8 operating hours
 Lubricate the grease nipple on the
pulley (1).
3
1
4
2
1
