LEMKEN Primus 10 - Main Tank

Layout and description
46
4.6 Main tank
The main tank is designed to hold water,
sprays and fertilisers.
The main tank is equipped with a tightly
closed cover (1).
Note: The tank opening is only intended
for repair work.
The level of the main tank is indicated on
the indirect level indicator (2).
In addition, the level can be displayed by
TankPilot via electronic level measure-
ment. The fill level can be read off from the
control centre and in the tractor cab.
The ventilation valve/ventilation system (3)
ensures the main container is ventilated
during distribution and vented during filling.
Internal cleaning nozzles (4) are provided
to clean the interior of the main tank with
clean water.
The device is equipped with a hydraulic
agitator (5).
The agitator is used to mix the carrier liquid
(water or fertiliser) with the spraying agent,
use it in an even concentration and hold it.
5
2
3
1
4
