Action Yes No
Step 9
Check the sensor (HCIT roller position) and make sure that it is properly
installed. If damaged, then replace the sensor. Go to “Sensor (HCIT pick
roller position) removal” on page 548.
Reseat the sensor connector on the controller PCBA and reseat also on
the other end of the sensor. POR the machine.
Does the error remain?
Go to step 10. The problem is solved.
Step 10
Open the right cover. Reseat the cable attached to the lift motor.
Does the error remain?
Go to step 11. The problem is solved.
Step 11
Open the right cover. Do a feed test, enter Diagnostics mode and navigate
to:
INPUT TRAY TESTS > Feed Test > Tray [x]
Does the lift motor run?
Go to step 12. Replace the lift motor.
See “HCIT lift drive
motor removal” on
page 544.
Step 12
Reseat all connectors on the controller PCBA.
Does the error remain?
Replace the controller
PCBA. See “HCIT
controller PCBA
removal” on page
541.
The problem is solved.
4063
Diagnostic information
117
