Fuser ID chip control jam service check
Action Yes No
Step 1
Ensure the fuser is properly installed.
Is the fuser properly installed?
Go to step 2. Reinstall the fuser.
Step 2
Remove the existing fuser, and install a different fuser.
Does the error remain?
Replace the fuser. See
“Fuser removal” on
page 459.
Go to step 3.
Problem solved.
Step 3
Ensure the cable for socket "J27" on the controller board is properly
connected.
Is the above connection properly connected?
Go to step 4. Reseat the connection.
Step 4
Ensure the LVPS connections are properly connected.
Are the above connections properly connected?
Go to step 5. Reseat the
connections.
Step 5
Reset the machine.
Does the error continue?
Replace the LVPS. Go to
“LVPS removal” on
page 511.
Go to step 6.
Problem solved.
Step 6
Reset the machine.
Does the error continue?
Replace the controller
board. See “Controller
board removal” on
page 492.
Problem solved.
203 paper jams
[x]‑page jam, remove standard bin jam. [203]
1 Firmly grasp the jammed paper on each side, and then gently pull it out.
Note: Make sure all paper fragments are removed.
4063
Diagnostic information
85
