Action Yes No
Step 2
Check the lower interface cable. If damaged, then replace the lower
interface cable. See Staple, hole punch lower interface cable removal”
on page 759.
Remove the left cover. Reseat the cable J15 on the controller PCBA, then
POR the machine.
Does the error remain?
Go to step 3. The problem is solved.
Step 3
Check the auto connector end of the machine below the finisher.
Is it free of damage?
Go to step 4. Replace the upper
interface cable of the
machine under the
finisher.
Step 4
Remove the left cover. Reseat the cable J11 on the controller PCBA, then
reseat the same cable on the sensor (paddle motor HP) end. POR the
machine.
Does the error remain?
Replace the sensor
(paddle motor HP). See
“Sensor (paddle motor
HP) removal” on
page 752.
If the error persists,
then go to step 5.
The problem is solved.
Step 5
Reseat the cable J5 on the controller PCBA, then reseat the same cable on
the motor end. POR the machine.
Does the error remain?
Go to step 6. The problem is solved.
Step 6
Check the paddle motor. If damaged, then replace the paddle motor. See
“Stapler paddle motor removal” on page 751.
Does the error remain?
Go to step 7. The problem is solved.
Step 7
Check the paddle assembly gear box:
Check the gears for damage
Check the sensor flag for damage
Is the paddle assembly gear box functional and free of damage?
Go to step 8. Replace the finisher.
See “Staple, hole
punch finisher option
removal” on page
738.
4063
Diagnostic information
188
