– 40X8739—Stapler main motor
– 40X8256—Stapler diverter motor
– 40X8722—Stapler diverter plunger assembly
– 40X8744—Stapler tray link assembly
– 40X7592—Sensor (stapler diverter plunger HP)
– 40X7592—Sensor (paddle motor HP)
– 40X8741—Stapler drive gear assembly
– 40X7592—Sensor (stapler rear door interlock)
– 40X8742—Stapler tray spring
– 40X8745—Sensor (stapler ejector HP)
– 40X7592—Sensor (media pusher HP)
– 40X8745—Sensor (throat media present)
– 40X8218—Stapler output bin LED
– 40X8743—Tamper assembly
– 40X7592—Sensor (left tamper motor HP)
– 40X7592—Sensor (right tamper motor HP)
– 40X8738—Stapler ejector motor assembly
– 40X8134—Sensor (stapler pass through)
– 40X8214—Stapler rear door
Mailbox option FRUs
– 40X8739—Mailbox main motor
– 40X7592—Sensor (mailbox rear door interlock)
– 40X8721—Mailbox option latch
– 40X8726—Mailbox main drive gear
– 40X8722—Mailbox diverter plunger assembly
– 40X8196—Mailbox top cover
– 40X8720—Mailbox top bin cover with bail
– 40X8719—Sensor (mailbox pass through)
– 40X8725—Mailbox top diverter spring
– 40X8723—Mailbox top diverter
– 40X8724—Mailbox middle diverter
• Parts catalog FRU (40X8693—Relocation kit (MX810)) was added.
July 9, 2013
• Added new information to the Fuser maintenance kits topic
• The following Option‑related service checks were revised:
– Finisher diverter jam service check
– Finisher left tamper jam service check
– Finisher right tamper jam service check
– Finisher tray holder jam service check
4063
Preface
33
