LHA4100 / LHA4200 Series
Technical Specifications
21
21.1 System
Operating System Linux (embedded)
Pentaplex Simultaneous View, Record, Playback, Backup &
Remote Monitoring
Number of Channels 4/8/16 Channels
21.2 Inputs/Outputs
Video IN 4/8/16 Channels
Video OUT
No
VGA OUT Yes
HDMI Yes
Audio IN 1 Line IN (RCA)
Audio OUT 1 Line OUT (RCA)
USB Port 1 at the back, 1 at the front
Alarm IN / OUT No
Video Output Resolution 4ch: 1920×1080, 1440×900, 1280×1024,
1280×720, 1024×768
8/16ch: 3840×2160, 2560×1440, 1900×1200,
1600×1200, 1680×1050, 1920×1080, 1440×900,
1280×1024, 1280×720, 1024×768
PTZ Control Yes
21.3 Display
Display Split 4ch: 1/4
8ch: 1/4/9
16ch: 1/4/9/16
Live Display Speed 4ch: 240fps @ 1080p, 100fps @ 3MP/4MP
8ch: 240fps @ 1080p/3MP/4MP
16ch: 480fps @ 1080p, 400fps @ 3MP/4MP
OSD ON/OFF
System Navigation USB mouse, IR remote control
Motion Area Setting NTSC: Fixed grid 1320 (44×30)
PAL: Fixed grid 1584 (44×36)
Sensitivity Levels
8
Firmware Upgrade Automatic over the Internet & via USB device and
network
User Authority By user group
Time Synchronization Auto time sync by NTP server
21.4 Recording
Video Compression
H.264
Audio Compression G.711
Resolution 4MP / 3MP / 1080p / 720p / 960H
#LX400086; r. 1.0/39246/39246; en-US
149
