Basic Setup
4
4.1 STEP 1: Connect the BNC cameras
Connect BNC cameras to the Video Input ports on the rear panel of the DVR. Push and
twist the BNC connector clockwise to secure it to the BNC port.
4.2 STEP 2: Connect the mouse
Connect the included USB mouse to one of the USB ports.
4.3 STEP 3: Connect the Ethernet cable
Connect the included Ethernet cable to the LAN port on the rear panel of the DVR. Con-
nect the other end of the Ethernet cable to a router on your network.
4.4 STEP 4: Connect the monitor or TV
Connect the included HDMI cable from the HDMI port to the TV or monitor
(recommended).
OR
Connect a VGA cable (not included) from the VGA port to the monitor.
#LX400086; r. 1.0/39246/39246; en-US
7
