General operation procedure
Lorrca Maxsis User Manual Page 115
Version 5.04 MRN-231-EN
It displays a coloured version of the diffraction pattern:
It is optional to adjust the camera gain (bar on the right side) until the diffraction pattern image
fills the entire viewing field (green light upper right of screen).
In case the "auto start" is enabled the measurement starts automatically when the temperature
has reached the correct value.
Press <START NOW>.
The measurement starts and the curve starts to appear.
7.4.4. Deformability curve result screen
At measurement completion measurement results are displayed on-screen, the software offers an
option to print (yes/no).
It is possible to print a measurement report by clicking the <P
RINT REPORT> button.
The latest results automatically overwrite the results file (Default name: Results.CSV). If enabled,
the results will also be written to other files (see “Settings/Files (on page 59)”). Return to the main
menu by clicking the <M
AIN MENU> button.
Check Deformability curve determination parameters explanation (on page 80)
