Installation
Page 48 Lorrca Maxsis User Manual
Version 5.04 MRN-231-EN
5.5.1. Instrument status
Function Description
At home position
LED is lit when CUP is at home position (= fixed position along cup
circumference where back-scatter intensity is acquired)
Intensity (au)
Back-scatter intensity (arbitrary units), should be within the range [0,
100] au during measurements (when blood is inserted).
BOB temperature Current BOB temperature in degrees Centigrade
Run motor at (rps)
Motor control. Set to desired cup revolution speed (rps = revolutions
per second).
During this test, the laser is turned on (flash) in order to enable back-scatter
intensity measurements.
