Lorrca MaxSis - Error Messages (Oxygenscan)

Trouble shooting
Page 154 Lorrca Maxsis User Manual
Version 5.04 MRN-231-EN
9.2. Error Messages (Oxygenscan)
Message Description Solution
No PT100 connected! No PT100 connected to the
device or PT100 not correctly
connected.
Check the PT100 presence and
its soldered connection to the
PCB.
No sensor connected!
No sensor is connected
(Amplitude < 1000).
Check the optical coupling to the
sensor, for example the fiber
head2sensor alignment
Signal amplitude too low! Signal amplitude < 3000. Check the optical coupling to the
sensor, for example the fiber
head2sensor alignment
SD card error! SD card not inserted or defect. Check the SD card presence and
functionality
Reference amplitude out of
range!
Contact service team
Device has to be sent to RRM for
service
Photo diode saturated! Ambient light too high or signal
strength too high
Send measurement sensor data
(Phase, Amplitude Temperature
and Calibration data, ideally the
repo) to RRM
Reference overflow! Reference strength too high. Contact service team. Device has
to be sent to RRM for service
Signal overflow! Signal strength too high. Decrease signal current.
PME timeout
Contact service team. Device has
to be sent to RRM for service
Pressure sensor defect! Pressure sensor out of function. Contact service team. Device has
to be sent to RRM for service
SD card full! SD card is full. Backup and wipe SD card
Pulse counter overflow! The pulse counter has reached
the pulse counter overflow limit.
Device has to be sent to RRM for
service
Temperature sensor not
available!
The temperature sensor was
activated but it is not present on
this device.
Device has to be sent to RRM for
service
