Lorrca MaxSis - Part 2 A

Page 188 Lorrca Maxsis User Manual
Version 5.04 MRN-231-EN
This picture is from a Lorrca without a cup. Please do not remove the cup!
11.4. Part 2a:
(applicable for Lorrca 109001)
Use another piece of foam and cut two blocks in the following size with a cut in the side to put it
over the pump plate.
L= in mm
