Lorrca MaxSis Program
Page 78 Lorrca Maxsis User Manual
Version 5.04 MRN-231-EN
6.6. Deformability curve determination screen
This screen appears when starting a deformability measurement. See Deformability curve (on
page 60) for details on the Settings parameters that influence the measurement.
A measurement starts after subsequently clicking <N
EW...(F1)>.
On this screen are shown:
1. Coloured diffraction pattern.
2. Curve display screen.
3. Indication of cell shape.
4. Measurement and sample details.
5. Measurement results.
