Lorrca MaxSis Program
Lorrca Maxsis User Manual Page 83
Version 5.04 MRN-231-EN
6.7.1.1. Oxygenscan parameters explanation
The following result parameters are given in Results file and printed report:
Parameter Description
# Measurement number
Start time Actual time that was valid after setting a new shear stress and
immediately following the image stabilisation time.
End time Actual time that was valid after the last EI measurement at the given
shear stress was performed.
Time (s) Time, in seconds, since the beginning of the measurement.
Coordinate count Number of coordinates in the iso-intensity curve that describes the
shape of the diffraction pattern.
A (pixels) Vertical axis of ellipse.
B (pixels) Horizontal axis of ellipse.
EI Elongation index
P02 (mm/Hg)
N2 (valve)
6.7.1.2. Explain Rinse gradient Oxygen screen
Screen R
INSE GRADIENT SYSTEM appears:
1. Open the hood.
2. Remove empty sample tube.
3. Place tube with demi-water (+/- 2,5 ml).
