Lorrca Maxsis User Manual Page 67
Version 5.04 MRN-231-EN
6.4.6. Oxygenscan options
This is only available when “Enable pO2 scan” is checked, and Oxygen scan module is available
on the instrument
Settings parameter Description Range
Enable pO2 axis Checkbox, Turns this option on/off
Logarithmic pO2 axis Checkbox
pO2 scan shear stress
(PA)
0-100
Determine pO2 every
(s)
0-3600
Moving average size
0-40
Calc area between:
0-250
...and (mmHg)
0-250
Scan steps see pO2 Steps (on page 68)
pO2 control Checkbox
pO2 control max.
speed (mmHg/min)
(visible when pO2 control is activated) For adjusting
deoxygenation
pO2 control P-term (visible when pO2 control is activated) For adjusting
deoxygenation
pO2 control I-term (visible when pO2 control is activated) For adjusting
deoxygenation
