Maintenance
Lorrca Maxsis User Manual Page 177
Version 5.04 MRN-231-EN
Continue the with the four other tube brackets
 Hook the first tube bracket onto the pump
frame. (Waste bracket)
Continue the with the rest of the tube brackets
This how it looks when all the tube brackets
are in place.
Tube to needle assembly
