Instrument description
Page 18 Lorrca Maxsis User Manual
Version 5.04 MRN-231-EN
Dimensions 40x40x40 mm
Laser
Wave length 655 nm
Focus distance 170 mm
output power Max 3 mW
Blood sample
Tube solution EDTA-Blood
Deformability test
+/- 25 l
Osmoscan
+/- 200 l
Oxygenscan
+/- 50 l
Tech specs Couette assembly
CUP
Inner Radius 16.01 ± 0.005 mm
Surface roughness Ra<0.026 µm
Material PMMA
BOB
Outer Radius 15.65 ± 0.005 mm
Surface roughness Ra<0.026 µm
Material PMMA
Ambient temperature + 4°C
Drive
Minimal cup speed 0.03 rps
Maximum cup speed 20 rps
Break time from sudden stop from
106 rpm to 0 rpm
<30 ms
Shear rate
0 - 800 s-1
Warming-up time Bob
Maximum 2 minutes
Heater
Heating accuracy ± 0.2 °C
Range 25 - 45 °C
Tech specs Gradient assembly
Gradient
mixer range 0 - 25 mS/cm
mixer accuracy ±-0.5 mS/cm
Reagents 50 - 500 mosm/kg
