Rigging work
12.1 Rigging work checklists for crane operation with the main boom
12 - 6 3 112 993 en Operating manual GMK 6400
12.07.2013
6. Depending on transport:
– Attach the hook block to the bumper;
à p. 12 - 110
– Set down the hook block and unreeve the hoist rope;
à Setting down the hook block, p. 12 - 112,
à Unreeving the hoist rope, p. 12 - 118.
7. For on-road driving without trailer:
– Turn superstructure to the 180° position to the front with the RCL
adjusted accordingly
– Place the main boom on the boom rest
8. For on-road driving with a trailer:
– Set down the superstructure on a trailer with the RCL adjusted accord-
ingly and switch on the boom floating position;
à p. 6 - 8
– Switch on slewing gear freewheel;
à p. 6 - 7
– Switch on boom pre-tensioning if necessary;
à p. 6 - 9
– Switch off the houselock;
à p. 11 - 15
9. Turn off the engine for crane operation;
à p. 10 - 17
