Rigging work
12.6 Outriggers
12 - 40 3 112 993 en Operating manual GMK 6400
12.07.2013
Pre-selecting outriggers
H
You can only pre-select outriggers on the side to which the hand-held con-
trol is connected.
• Press the button for the required outriggers
once:
Pre-selection is switched on and the lamp in
the corresponding button lights up, e.g. the
lamps (5).
After about 10 seconds, the pre-selection is
switched off.
Extending/retracting outrigger beams
• Observe the safety instructions for operating the outrigger beams;
à p. 12 - 37.
• Press the button combination for the desired movement:
The pre-selected outriggers move until you let go of the respective button
or until the respective end position has been reached.
1 Front left
2 Front right
3 Rear left
4 Rear right
1 + 3 Both on left
2 + 4 Both on right
1 Extend
2 Retract
