Rigging work
12.6 Outriggers
12 - 48 3 112 993 en Operating manual GMK 6400
12.07.2013
Extending/retracting supporting cylinders
• Observe the safety instructions for operating the supporting cylinders;
à p. 12 - 45
• Press the button combination for the desired movement:
The pre-selected supporting cylinders move until you let go of the respec-
tive button or until the respective end position has been reached.
From the crane
cab
The following operating elements are found in the
Outriggers submenu.
Starting the engine
• Start the engine from the crane cab; à p. 10 - 8.
• Switch off the slewing gear.
Opening the submenu
• If necessary, open the main menu ö and press the (1) button once.
The
Outriggers submenu opens.
1 Extend
2 Retract
