Rigging work
12.6 Outriggers
Operating manual GMK 6400 3 112 993 en 12 - 53
12.07.2013
Automatic
alignment
During the automatic alignment procedure, the supporting cylinders are
only extended to prevent any wheels from touching the ground after the
alignment.
• Check that the prerequisites are met; à p. 12 - 51.
• Extend the supporting cylinders until the outrigger pads are just above
the ground.
Starting procedure
Depending on the truck crane's equipment, you can start the procedure
from the hand-held control and the
Outrigger control units.
– On the hand-held control
• Press the (1) button once.
• Press the (2) button once.
The lights in the buttons go on.
• Press the button combination (3) for automatic alignment.
The procedure begins.
– On the control units
• Press the (1) button.
• Additionally, press the button (2).
The procedure begins.
