Rigging work
12.7 Rigging/unrigging the counterweight
Operating manual GMK 6400 3 112 993 en 12 - 73
12.07.2013
When rigging
• Take the cover (2) out of the holder (1).
• Place the cover (2) on the recesses of the
slinging points (3) such that it does not slip.
• If necessary, place more 10 t plates onto the
cover (2).
When unrigging
• Remove the cover (2) from the recesses (3)
of the slinging points.
• Place the covers (2) into the holders (1) and
secure them.
• If necessary, remove the 10 t plates.
G
Risk of accident due to uncovered openings
Cover the recesses of the slinging points with the covers provided. In this
way you avoid stepping into the recesses and injuring yourself.
Do not just place the cover on the last pair of 10 t plates. When you place a
cover onto every pair of right and left 10 t plates, then there is no danger of
tripping when unrigging.
