CSP−900RMM−2MD Helicopters, Inc.
Rotorcraft Maintenance Manual
Page 217
Revision 35
06-00-00
Legend (Ref. Figure 211) (Cont.)
Item
No.
Removal and Installation
Permits Access ToName
Item
No.
Method
Ref.
Figure 204
TypeQuantity
Permits Access ToName
AL230 Cabin Floor Left Aft
Access Cover
Left Aft Fuel Vent Valve, Fuel
Cell
13 Screw L
AL250 Baggage Floor Left
Outboard Panel
Fuel Tee Fittings, Fuel Pressure
Switch Drain Tubing, Fuel Hose
Shrouds, Fuel Catch Can
25
4
Screw
Bolt
L
M
AR129 Cockpit Outboard
Right Floor Panel
Fire Overheat Bleed Air Leak
Control, Wire Harness, RH
Static Port
34
1
Screw
Bolt
L
M
AR138 Cockpit Floor Right
Access Panel
Flight Control Tubes,
Bellcranks, Throttle Cables
35 Screw L
AR145 Pilots Collective Base
Access Panel
Pilots Collective Base, Link
Assembly, and Mounting
Bracket
4 Screw L
AR155 Cabin Floor Right
Forward Access
Cover
Right Forward Fuel Vent Valve,
Fuel Cell
12 Screw L
AR165 Cabin Floor Right
Outboard Panel
Fuel Cell Frangible Valve,
Heat/Defog Bleed Air Line, Fire
Overheat Bleed Air Leak
Detector
76 Screw L
AR230 Cabin Floor Right Aft
Access Cover
Right Aft Fuel Vent Valve, Fuel
Cell
13 Screw L
AR250 Baggage Floor Right
Outboard Panel
Fuel Tee Fittings, Fuel Pressure
Switch Drain Tubing, Fuel Hose
Shrouds, ECS Tubing, Strobe
Power Supply, Fuel Catch Can
25
4
Screw
Bolt
L
M
To Next Page
