Table 203. RMM Troubleshooting IIDS Abbreviations (Cont.)
Secondary Display on IIDS Abbreviation
CABIN HEAT WARNING ANNUNCIATOR (RED) CAB HEAT WARNING
BATTERY HOT WARNING ANNUNCIATOR (RED) BAT HOT WARNING
BATTERY WARM CAUTION ANNUNCIATOR (YELLOW) BAT WRM CAUTION
ROTOR BRAKE CAUTION ANNUNCIATOR (YELLOW) ROTOR BRAKE CAUTION
CABIN DOOR OPEN CAUTION ANNUNCIATOR (YELLOW) CABIN DOOR OPEN CAUTION
BAGGAGE DOOR OPEN CAUTION ANNUNCIATOR (YELLOW) BAGGAGE DOOR OPEN CAUTION
HYDRAULIC SYSTEM CAUTION ANNUNCIATOR (YELLOW);
ASSOCIATED IIDS A/N DISPLAY DEFINES LOW PRESSURE or
HIGH TEMPERATURE
1 HYD
HYD 2
1 HYD 2
IIDS FAULT ANNUNCIATOR (YELLOW) IIDS FAULT CAUTION
TIME OF DAY DIGITAL DISPLAY (WHITE) TOD DD
OUTSIDE AIR TEMPERATURE DIGITAL DISPLAY in °C (WHITE) OAT °C DD
Primary Display on IIDS Abbreviation
IIDS ALPHANUMERIC DISPLAY IIDS A/N display
LEFT ENGINE TORQUE DIGITAL DISPLAY (WHITE) L ENG TORQUE DD
RIGHT ENGINE TORQUE DIGITAL DISPLAY (WHITE) R ENG TORQUE DD
LEFT ENGINE EGT DIGITAL DISPLAY (WHITE) L ENG EGT DD
RIGHT ENGINE EGT DIGITAL DISPLAY (WHITE) R ENG EGT DD
ROTOR NR DIGITAL DISPLAY (WHITE) ROTOR NR DD
LEFT ENGINE GAS TURBINE RPM%, NP DIGITAL DISPLAY
(WHITE)
L ENG NP DD
RIGHT ENGINE GAS TURBINE RPM%, NP DIGITAL DISPLAY
(WHITE)
R ENG NP DD
ENGINE OUT WARNING ANNUNCIATOR ENG OUT WARNING
EEC MINOR FAULT CAUTION ANNUNCIATOR (YELLOW) EEC CAUTION
EEC MANUAL MODE CAUTION ANNUNCIATOR (YELLOW) EEC, MAN CAUTION
EEC FAILURE WARNING ANNUNCIATOR (RED) EEC, FAIL WARNING
RED BAR SEGMENTS ARE WARNING RED SEGMENT
