Table 203. RMM Troubleshooting IIDS Abbreviations (Cont.)
Primary Display on IIDS Abbreviation
SAMPLE: RED BAR SEGMENTS L ENG EGT RED SEGMENT
YELLOW BAR SEGMENTS ARE CAUTION YEL SEGMENT
GREEN BAR SEGMENTS ARE NORMAL GRN SEGMENT
WHITE IS ADVISORY INFORMATION
RED WARNING TICK MARK WARNING TICK MARK
IIDS CONTROL KEYS:
(CLR) IIDS ACKNOWLEDGE AND CLEAR DISPLAY KEY IIDS CLR KEY
(MENU) IIDS DISPLAY MENU KEY IIDS MENU KEY
( ↑ ) IIDS UP ARROW KEY IIDS UP KEY
( ↓ ) IIDS DOWN ARROW KEY IIDS DWN KEY
(ENT) IIDS ENTER MENU KEY IIDS ENT KEY
(REC) IIDS RECORD KEY IIDS REC KEY
(DISP) IIDS DISPLAY MODE KEY IIDS DISP KEY
IIDS Alpha−Numeric Display Abbreviations
EXHAUST GAS TEMPERATURE EGT
GAS GENERATOR SPEED NG
POWER TURBINE SPEED NP
ENGINE OIL PRESSURE EOP
ENGINE OIL TEMPERATURE EOT
MAXIMUM ENGINE TORQUE LOCAL Q
ROTOR SPEED NR
TRANSMISSION OIL PRESSURE XOP
TRANSMISSION OIL TEMPERATURE XOT
HYDRAULIC OIL PRESSURE HOP
