Mindray DC-3 User Manual

Image Recording
20-2
z To record,
1
Connect the VCR recorder to the ultrasound system and put a cassette in the recorder.
2
Set the VCR recorder through the following path: [Setup] → [Peripheral Preset]→ [I/O
Config].
3
Start the ultrasound exam and acquire images.
4
z Press the user-defined key (preset in the [Key Config] screen) on the control panel.
Or
z Move the cursor onto the menu title to navigate to the VCR Record selection and
press <Set> to show the VCR Record menu. Or
z Click icon in the lower right corner of the screen.
5
Move the cursor onto Record / Pause selection and press <Set> to enter VCR
recording status and record images.
6
Press the user-defined VCR record key a second time, or move the cursor onto Record
/ Pause selection and press Set, to stop recording.
7 Repeat the steps 3 through 6 as needed to record multiple segments of images.
8
Press [Stop Record] in the VCR Record menu to stop recording.
9
Press [Eject] to remove the VCR cassette.
NOTE:
After the cassette has recorded data and been taken out / re-inserted, you will need
to select [blank search] from the front of the VCR to find the next blank tape position.
Subsequent recording can overwrite existing data.
20.1.3 Replay
To replay the recorded images using VCR,
1 Connect the VCR recorder to the system and place the cassette with recorded data.
2
Press the user-defined key for VCR replay on the control panel, or move the cursor onto the
menu title to navigate to the Other selection and press <Set> to show the Other menu.
Select Video in the Other menu and press <Set> to enter the VCR replay. The screen
displays the following screen.
