Parameter Setup
17-5
17.8 Soft-Key and Menu Preset
You can preset parameter items in image modes for all types of transducers, in the soft
menu (displayed at the bottom of the screen) and the menu (displayed on the upper left
side of the screen), as well as parameter items for 3D capture, 3D review, PW mark,
Reset ROI. In addition, you can preset parameter items in freeze status and cine review
status.
îš„ Open the [Soft-Key and Menu Preset] screen
To open the [Soft-Key and Menu Preset] screen, press [Setup] and select Key and Menu
Preset. The default is the currently-used transducer in the current image mode.
îš„ Preset Operations
Since the preset operations are the same for different image modes and statuses, the
following case (linear transducers in real time B mode) is taken as an example.
1． Parameter Items Displayed in Soft Menu
The system has factory settings for parameter items displayed in soft menu; however,
you can preset or customize them according to your preferences.
To preset parameter items in soft menu, enter [Image Params] page in the [Soft-Key
and Menu Preset] screen, select Probe Type as Linear and select Image Mode as B.
Open the [Softkey] page on the right side. See the figure below.
