5 Set-up & Connections
5.1 System Set-up
Please read and understand the safety precautions before placing the system.
1 Unlock the four casters.
2 Move the system by holding the handle.
3 When you move the system to a desired location, lock the four casters.
4 Leave at least 20cm at the back and both sides of the system.
CAUTION:
Maintain a generous – free air flowing space around the back and
both sides of the system; failure may result due to increased rise
in system operating temperature.
5.2 Connecting Power Cord & Protective
Grounding
5.2.1 Connecting the External Power Supply
The power supply for this system must meet the following requirements:
z 100 to 127V or 220 to 240V
z 50Hz / 60Hz
z Power consumption: greater than 600VA
The connection method is described as follows:
1
Push the retaining clamp upward, and insert the power plug into the receptacle, as
shown in the figure below.
