Set-up & Connections
5-7
To remove the USB memory device:
1
Click to open the [Remove USB Device] screen.
2
Select the memory device to be removed.
3 Click [OK] and you can hear a sound.
4
Remove the USB memory device.
5.6 Installing a Graph / Text Printer
As shown in the figure below, a graph / text printer has a power cord and data cable. The
power cord shall be directly connected to a wall receptacle as required.
To install the printer:
1 Connect the data cable to a USB port of the system.
2
Connect the power cord of the printer to a wall receptacle.
3
Turn on the power of the ultrasound system and the power of the printer.
4
Press [Setup] key on the control panel to show the [Setup] menu.
5 Click [Peripheral Preset] to open the [Peripheral Config] screen.
6 The [Printer] page is opened by default.
7 Click [Add Printer] button to open the [Browse] screen.
8 Select the specific path for installation and click [OK] to install it.
USB port
Power cord
Data cable
To Next Page
