7-1
7 Basic Screen and
Operation
7.1 Basic Screen
The system monitor displays ultrasound images, parameters, menus and measurement
results window.
The following diagram maps out the different areas, such as patient information, image
parameter & menu, image-in-image thumbnail, image area, thumbnail of images saved,
body mark, help information & cursor icon, soft menu, and system status icon.
Manufacturer
Logo
Hospital Name Acoustic Power & MI/TI
Thumbnail Area of
Images Stored
Image Area
Image Parameter
& Menu Area
Body Mark Area
Soft Menu Area
Exam Date & Time
Patient Information
Probe
Exam Mode
Operator ECG Icon
Freeze Icon
Accession #
Image-in-Image
Thumbnail
System Status Icon
Area of Help Information & Cursor Icon
7.1.1 Information Area
The information area displays manufacturer logo, hospital name, exam date & time,
acoustic power & MI/TI, freeze icon, patient information, transducer model, current exam
type, operator’s name or patient gender or patient age (can be set), ECG icon (if ECG
module is connected), and accession #, etc.
