Exam Types
9-3
9.3 Setting Exam Types
1 In the [Setup] menu, select the [Exam Preset] item to enter the [Exam Preset]
screen. Or
2 Press the [Probe] key to open the [Select Probe & Exam] screen and click the [Exam
Preset] button to enter the [Exam Preset] screen.
The [Exam Preset] screen consists of two pages: Exam Selection and Exam Config.
9.3.1 Exam Selection
After the [Exam Preset] screen is entered, the screen will display the [Exam Selection] page,
as shown in the figure below. This page is used to assign an exam type to a specific
transducer.
The selection method is described as follows:
1
To select a transducer, move the cursor onto the column ,
and select the transducer model through the drop-down menu.
2
On the right side of the screen, you can view the exam types supported by the current
transducer. On the left side, you can view all the exam types supported by the system,
i.e., Exam Library.
3
To delete an exam supported by the current transducer, select the exam first, and then
click
to delete it.
4
To add an exam for the current transducer,
1) Select the exam from the Exam Library on the left and click
to add it
