3-12 System Preparation
 Menu title
Displays the menu name.
 Tab
Divide the menu items according to measurement conditions.
 Page-turning button
When there are too many items in a menu, the items will be divided into more
than one page.
You can turn pages by page-turning buttons, and .
 Items
Refers to the items on a menu. For item that is applicable for more than one
mode, the item appears as shared item in the certain mode. Items of image
modes and measurement can be preset.
 Down-drop list button
If there are several options available for one item, you can choose the options
through the button.
 Return to previous menu
Click [Return] to return to the previous menu.
The multifunctional knob can be used to operate the menu. Press the knob to
open the menu; rotate the knob to navigate through the items one by one, and
press it to select the item.
Depending on the item types, the multifunctional knob can:
 For a commanding item or command optional item: press the knob to directly
activate the item.
 For a parameter item or ON/OFF item: press the knob to lock and select the
item, then rotate the knob to switch among the available values; press the
knob again to release and deselect the item.
Menu title
Tab
Drop-down list
button
Items
Shared items
Page-turning
button
Page-turning
button
