Chapter 4: Specifications
Endpoints
Page 4-40 Inter-Tel
®
5000 Installation Manual – Issue 2.4, May 2008
Endpoints
A variety of IP endpoints can be used on the Inter-Tel 5000 platform. The combination of
endpoints depends on the number and type of endpoint modules installed. For endpoint
illustrations and endpoint feature description, refer to the Inter-Tel 5000 Features and
Programming Guide (part no. 580.8006).
At least one display endpoint should be installed to allow an administrator the capability of
seeing system alarm messages, program system data, and receive unsupervised CO recalls.
When the system is in the default configuration, extension number 1000 is preassigned as an
administrator and as the primary attendant.
For reference, the following tables show approximate endpoint dimensions.
IP Devices
The Inter-Tel Protocol (ITP) IP PhonePlus, multi-protocol endpoints, and IP Single Line
Adapters (SLA) provide the functionality that allows the user to make calls through the IP
network to the converged communications platform.
The Model 8690 is a multi-protocol display endpoint that uses Windows CE as the interface.
The IP devices operate the same as their counterparts installed directly on the system, except
that IP devices:
• Cannot use a MDPM.
• Cannot support a full DSS/BLF.
• Do not support Desktop OAI applications.
• Do not need to support the Enhanced Speakerphone Mode feature.
The IP SLA operates like a standard single line endpoint.
Table 4-19. Model 86008620/8622/8662 Dimensions
8600 8620/8622/8662
Dimension
Measurement (Metric)
Dimension
Measurement (Metric)
Height
2.5 in. (6.4 cm)
Height
2.5 in. (6.4 cm)
Width
6.4 in. (16.3 cm)
Width
8.8 in. (22.3 cm)
Length
8.3 in. (21.1 cm)
Length
8.3 in. (21.1 cm)
Weight
2.1 lb (0.9 kg)
Weight
2.7 lb (1.2 kg)
