Chapter 4: Specifications
IP (Only) Endpoints
Page 4-42 Inter-Tel
®
5000 Installation Manual – Issue 2.4, May 2008
IP (Only) Endpoints
The Inter-Tel 5000 platforms support the following IP-only endpoints:
• Model 8660 – 6-Line Display
• Model 8664 – 2-Line Display 802.11b Wireless
• Model 8665 – 2-Line Display 802.11b Wireless
• Model 8668 – 2-Line Display 802.11b Wireless
• Axxess (10Base-T) IP PhonePlus, which operates in Inter-Tel Protocol (ITP) mode
• Eclipse IP PhonePlus, which operates in ITP mode
• Mitel Model 5000-series endpoints
Mitel IP Endpoint Specifications
Table 4-21 shows Mitel IP endpoint specifications.
Table 4-21. Mitel IP Endpoint Specifications
a
a. Not all features are supported across all IP platforms.
Specification Model 5212 Model 5224 Model 5330 Model 5340
Size (L x W x H) 9.5” x 8” x 4.5”
(24 cm x 20.5 cm x 12 cm)
Ports 2
Power Output: 48VDC
250 mA
Input: 100V to 240V
50 to 60 Hz
LAN Power: 802.3af
PoE
Output: 48VDC
250 mA
24VDC 1.7A
(reserved for future
use)
Input: 100V to 240V
50 to 60 Hz
LAN Power: 802.3af
PoE
Output: 48VDC
250 mA
802.3af PoE
Input: 100V to 240V 50 to 60 Hz
LAN Power: 802.3af PoE
Power
Consumption
3.9 W 4.8 W
Processor Type ARM946E-S MIPS
Processor Speed 140 MHz 165 MHz
DSPs N/A 1
DSP Speed N/A 74 MHz 125 MHz
Silicon (Processor) 0.18µ CMOS 0.13µ CMOS
Codec/Wideband N/A G.722
(currently not supported)
RAM 8 MB 16 MB
ROM 2 MB 8 MB
Voice Traffic RTP over UDP
Signaling MiNet over TCP
Ethernet/Voice QoS IEEE 802.1p/q
Weight 2.8 lbs. (1.3 kg)
Mean Time Before
Failures (MTBF)
10 years
Codec/Compression G.711, G.729a
