Chapter 4: Specifications
Multi-Protocol Endpoints
Inter-Tel
®
5000 Installation Manual – Issue 2.4, May 2008 Page 4-41
Multi-Protocol Endpoints
The following multi-protocol endpoints support the Inter-Tel Protocol (ITP) mode and restricted
functionality of the Session Initiation Protocol (SIP) mode:
• Model 8600 – No Display
• Model 8620/8622 – With 2-Line Display
• Model 8662 – With 6-Line Display
• Model 8690 – With Multimedia Touchscreen
Multi-functional endpoints operate differently when in SIP mode rather than ITP mode. For
details about the features available and how to program an endpoint to operate in SIP mode,
refer to the SIP Server Installation and Configuration Manual, part no. 835.2605.
The software license regulates the number of Inter-Tel multi-protocol endpoints that can be
operated on the system. Features supported on multi-protocol endpoints appear in Table 4-20
on page 4-41.
* Can be programmed as a feature, secondary extension, or DSS button.
IMPORTANT
To operate in SIP mode, SIP Server v1.1 is required.
Table 4-20. Multi-Protocol Endpoint Features
Feature
Model
8600
Model
8620
Model
8622
Model
8662
Model
8690
2-Line Display X
2-Line Display with 2 Ethernet Ports X
6-Line Display X X
12-Key Push button Keypad X X X X
ITP Mode X X X X X
SIP Mode X X X X X
Dedicated Headset Jack X X X X
Call and Intercom Buttons X X X X
Hearing Aid Compatible (HAC)
Handset
XXXX X
Hold Button X X X X X
Menu Buttons X X
Message Lamp X X X X X
Microphone X X X X X
Programmable Buttons
*
XXX
Ring and Voice Volume Control X X X X X
Speaker X X X X X
Speakerphone On/Off Control X X X X
Special Button X X X X X
Stylus X
Touch Screen Display with
Windows
®
CE-OS
X
