Chapter 4: Specifications
System-Wide Specifications
Inter-Tel
®
5000 Installation Manual – Issue 2.4, May 2008 Page 4-5
System-Wide Specifications
Important system-wide specifications appear in the following subsections.
Loop Limits
Table 4-2 identifies the maximum distances from the Inter-Tel 5000 Base Server to which digital
and single line endpoints can be installed.
Power Supply
Built into the CS-52xx chassis, the 40 W power supply provides power ot the chassis and
modules. The chassis must be connected to an isolated, dedicated, 105–125 VAC, 15 A
(minimum), 57–63 Hz, single-phase commercial power source through an uninterruptible power
supply (UPS). The system power supply provides +5 VDX, 4 A output.
Built into the DEI chassis, a 100 W power supply provides power to the chassis and modules.
For universal operation, each chassis must be connected to an isolated, dedicated, 90–240
VAC, 15 A (minimum), 50/60 Hz, single-phase commercial power source through a (UPS). The
DEI power supply provides +24 VDC, 5.3 A output. For expanded applications, all required
power transformers should be plugged into appropriate power sources. For details, refer to the
equipment manufacturer’s documentation.
In addition to the system power back-up, a rechargeable battery located on the system
Processor Module backs up the database. In the event of a power failure or brownout condition,
this battery supports the module for up to one day. The battery automatically recharges when
power is restored to the module.
Table 4-2. Loop Limits for Digital and Single Line Endpoints
Endpoints
Port
Impedance
Loop Limit
(24 AWG)
From Base Server chassis:
• To a single line endpoint or playback device connected to
the built-in port
• To a single line endpoint or playback device driven by a
SLM-4 port
From DEI chassis: To a single line endpoint or playback device
driven by a SLM-8
600 Ω 2000 ft
(609 m)
REN 3.0
From DEI chassis:
• To digital endpoints
• To a digital endpoint equipped with PCDPM and MDPM and
connected to DSS unit(s) or SLA
62
Ω 1200 ft
(366 m)
From an MDPM: To a single line endpoint 195
Ω 3800 ft
(1158 m)
From an SLA: To single line endpoints or playback devices.
Supports facility code OL13C.
800 Ω 15,560 ft
(4742 m)
NOTICES
Do not use an extension cord.
Do not plug any other equipment into the outlet where the UPS supporting the Base Server
or DEI is plugged-in.
Do not defeat, or leave floating, the ground wire in the AC power cord.
