Chapter 6: Reference
Cables
Inter-Tel
®
5000 Installation Manual – Issue 2.4, May 2008 Page 6-9
Cables
Table 6-9 identifies cables required to install and maintain Inter-Tel 5000 platform equipment
and selected peripherals.
Direct Station Select (DSS)/Busy Lamp Field (BLF) Equipment
Table 6-10 summarizes equipment, cables, and parts needed to connect the Mini-DSS Unit to
IP endpoints and DSS/BLF units to digital endpoints that operate on Inter-Tel 5000 platforms.
Table 6-9. Inter-Tel 5000 Equipment and Peripheral Cables
Description Part No.
Cable Assy, DB15 to 2x7 Female Twist Ribbon 813.1821
Voice Processor Expansion Cable 813.1806
Mitel 48VDC Ethernet Power Adaptor 100–240V 50–60Hz(ES) 50005301
Mitel 24VDC C7 Power Cord with U.S. Plug Type 51005172
Digital Expansion Interface (DEI) Cable
See Table 6-8 on page 6-8.
Digital Endpoint Module (DEM-16) Adapter (Quad RJ-45 to Amp), 15 ft
See Table 6-8 on page 6-8.
PCDPM-to-Endpoint Interface Cable
See Table 6-10 on page 6-9.
PCDPM-to-MDPM Interface Cable
See Table 6-10 on page 6-9.
Table 6-10. DSS/BLF Units, Data Port Modules, and Transformers
Description
Part No.
[Europe]
16-Key Mini-DSS 550.8416
Model 8450, 50-Button, 10-row x 5-column 550.8450
60-Button, 12-row x 5-column 560.4000
60-Button, 6-row x 10-column 550.4200
PC Modem Data Port Module (PCDPM)
Executive or Standard Display endpoints
(does not require an external AC transformer)
550.3018
[PB2585]
PC Modem Data Port Module (PCDPM)
Models 8520 or 8560 endpoints
(Does not require an external AC transformer.)
550.8400
[PB2612]
Modem Data Port Module (MDPM)
Executive Display, Standard Display, Models 8520, or 8560 endpoints
(Includes PCDPM-to-MDPM cable and AC transformer.)
550.3015
[PB2549-A]
PCDPM-to-Endpoint Interface Cable 813.1567
[C108]
PCDPM-to-MDPM Interface Cable 813.1566
[C107]
Transformer for PCDPM and MDPM units (24 VAC,450 mA) 806.1045
