Chapter 6: Reference
Endpoints and Endpoint Features
Inter-Tel
®
5000 Installation Manual – Issue 2.4, May 2008 Page 6-13
Endpoints and Endpoint Features
Figure 6-1 through Figure 6-13 show endpoints and endpoint features supported on the Inter-Tel
CS-5200, CS-5400, and CS-5600 platforms.
Figure 6-1. Model 8600 Endpoint
RING AND VOICE
VOLUME
CONTROLS
SPECIAL
BUTTON
MESSAGE LAMP
CALL AND
KEYPAD
SPEAKERPHONE
ON/OFF
CONTROL
SPEAKER
MICROPHONE
(UNDERNEATH)
INTERCOM
BUTTONS
HOLD
(RED)
BUTTON
HEARING
AID
COMPATIBLE
(HAC)
HANDSET
To Next Page
