Chapter 6: Reference
Endpoints and Endpoint Features
Page 6-14 Inter-Tel
®
5000 Installation Manual – Issue 2.4, May 2008
Figure 6-2. Model 8620/8622 Endpoint
MESSAGE LAMP
CALL AND
INTERCOM
2-LINE LCD DISPLAY
BUTTONS
KEYPAD
BUTTONS
RING AND VOICE
VOLUME
CONTROLS
SPEAKERPHONE
ON/OFF
CONTROL
SPEAKER
HEARING
AID
COMPATIBLE
(HAC)
HANDSET
PROGRAMMABLE
MICROPHONE
(UNDERNEATH)
DEDICATED
HEADSET
JACK
(UNDERNEATH)
HOLD
(RED)
BUTTON
SPECIAL
BUTTON
NOTE
The Model 8622 provides two Ethernet ports on the bottom of the endpoint. The
Model 8620 provides one port.
