Endpoints and Endpoint Features
Inter-Tel
®
5000 Installation Manual – Issue 2.4, May 2008 Page 6-15
Figure 6-3. Model 8660/8662 Endpoint
MESSAGE LAMP
CALL AND
6-LINE LCD DISPLAY
BUTTONS
12-KEY PUSHBUTTON
KEYPAD
VOLUME
CONTROLS
SPEAKERPHONE
ON/OFF
CONTROL
SPEAKER
HEARING
AID
COMPATIBLE
(HAC)
HANDSET
RING AND
VOICE
INTERCOM
BUTTONS
HOLD BUTTON
(RED)
PROGRAMMABLE
MICROPHONE
(UNDERNEATH)
DEDICATED
HEADSET
JACK
(UNDERNEATH)
MENU
BUTTONS
MENU BUTTONS
SPECIAL
BUTTON
NOTE
The Model 8660 provides two Ethernet ports on the bottom of the endpoint. The
Model 8662 provides one port.
