Mitel Inter-Tel 5000 - Connecting Station Cables to a European System

Chapter 5: Installation
Connecting Station Cables to a European System
Inter-Tel
®
5000 Installation Manual – Issue 2.4, May 2008 Page 5-81
Figure 5-46. DEM-16 Block Terminations for Endpoints on European System
Female Amphenol-Type Connectors
126
1-16
1234567890
Use non-conducting
plastic connector covers
25-Pair
To Endpoint or SLA
WH/BL
BL/WH
5
3
1
6
4
2
1234567890
cable from
MDF
To DEI and DEM-16s
Amphenol-Type
Connector
to DEM
adapter cable*
*Available Adapter Cable:
15 ft (4.5720 m) with Amphenol, part no. 813.1814
W/BL-Y/BL
